Silencer 56SL - Group 1; Group 2

UM_FULL_56SL_REV_A 14
GROUP 1 (One Flash of Parking Light)
Chirps Shutdown Mode Solution
1
Hood Open
• Close the hood.
• Check 14-pin White/Black wire connection.
2
Optional Enable Switch OFF or Black/
White must have a ground
• Check 14-pin Black/White wire connection.
• Move the Enable Toggle Switch to “ON” position. (If installed.)
Move the gear selector to “Park”/ “NEUTRAL” position
3
Foot Brake on
• Check 14-pin White/Violet wire connection
• Release Foot Brake.
4
System is in Valet Mode Exit the Valet mode
5
Hi Voltage
(Voltage Checking Type)
Set the “Feature 3-02 to “Low Level”
Low or No RPM
(Tachometer Checking Type)
• Check 14-pin White/ Red wire connection
• Set the “Feature 3-02 to “Hi Level”
• Re-learning the RPM
6
The engine has run successfully but
is still starting (Tachometer Checking Type)
• Set the “Feature 3-02 to “Low Level”
GROUP 2 (Two Flash of Parking Light )
Chirps Shutdown Mode Solution
1
Over-Rev Shutdown
2
Running Time expired
3
Transmitter Shutdown
