3. NX2/NEXUS NETWORK ERROR MESSAGE WITH CAUSE
AND REMEDY
If an error message [Err #] is displayed on any instrument, an error has been
detected by NX2/NEXUS Network.
The message can assist you to diagnose the cause and remedy the error.
To escape from an error message, press any push-button. If not possible to escape,
reset power (turn off and on again), then make the remedy if suggested below.
Note! For errors marked with [*], most probably the unit needs a rectification.
Errors marked with [¤] is only relevant for old products, GPS Antenna
21000, and GPS Compass /XL1000.
No. Message and cause * Remedy
01 Activated watchdog timeout.
Stack error
* Reset power.
02 NEXUS Network data frames are
missing.
Check connections and set-up.
03 No data received within approx. 10 sec. Check connections and power voltages.
04 EEPROM read error. * Reset power.
05 EEPROM write error. * Reset power.
06 RAM memory Read-error. * Reset power.
07 Autolog full in GPS Compass. Clear Autolog memory.
08 Break reset. * Reset power.
09 EEPROM auto initalisation, or
NMEA transmit fail. (NX2/NEXUS
Server only).
* Reset power.
10 Range error, depending on wrong
input e.g. 17° 70' = too many minutes.
Correct input format.
11 Remote control calibration error.
Command can not be executed .
Check connections and settings.
12 No response from navigator. Check navigator connection and settings.
13 Waypoint not defined. Define a waypoint.
14 Impossible command when used
with an external NMEA navigator.
Use only possible command.
15 Impossible command when in
autopilot mode.
Use only possible commands.
16 Auto-deviation is not possible.
NMEA Compass selected?
Check for extreme magnetic field, upside
down mounting of transducer or wrong
transducer type setting. NMEA Compass?
17 Auto-deviation check failed. 1¼ turn not completed or extreme magnetic
disturbance.
18 Auto-deviation. Function denied. Function denied since compass is busy with
the auto-deviation routine.
19 Auto-deviation failure.
Error larger than 1.5°. The boat probably hit a
wave during the turn.
20 GPS to CPU communication error. *¤ Reset power.
21 GPS aqusitition failure (time out). ¤ Maximum allowed time for searching
satellites. E.g. when try to navigate indoors.
Check GPS antenna location.
22 CPU to GPS communication error. *¤ Reset power.
