Silvercrest SDBSB 3000 A1 - Appliance Description and Symbols; Appliance Component Identification; Appliance Symbol Meanings

SDBSB 3000 A1
■ 8
│
GB
│
IE
Appliance description
(See fold-out page for illustrations)
Figure A:
1 Heat-up indicator lamp
2 Steam button
3 Temperature control
4 Lock switch
5 Connecting hose
6 Stand
7 Steam chamber closure (underside)
8 Soleplate
Figure B:
9 Filler opening
0 Water tank
q Cleaning brush
Figure C:
w Water tank control lamp
e On/Off button
r On/Off control lamp
t clean control lamp
z Steam control lamp: high
u Steam control lamp: medium
i Steam control lamp: low
o
+
button (increase steam intensity)
p
‒
button (decrease steam intensity)
Symbols on the appliance
Symbol Meaning
Continuous steam volume (140g/min)
Power output (3000W)
Ceramic-coated soleplate
Automatic switch-off
