After use
Store the main unit
4
after use
either by hanging it on the wall
bracket
5
(see Fig. C) or lying it
out of the reach of children and
pets in a protected location where
no one can trip over or step on
the main unit
4
with aluminium
suction tube
15
or the mains
cable.
Charge the rechargeable battery
2
again after
use (see chapter “Charging the rechargeable
battery”).
The aluminium suction tube
15
and the electric
floor brush
13
can be left attached to the main
unit
4
during storage.
Storing the accessories:
Store the dust brush
11
and crevice nozzle
12
in the accessory holder
10
(see figure).
Put the accessory holder
10
on the aluminium
suction tube
15
.
15
12 11 10
15
11 1012
Then either hang the main unit
4
on the wall
bracket
5
(see Fig. C) or place it out of the
reach of children and pets in a protected
location.
Note: Before vacuuming, remove the accessory
holder
10
from the aluminium suction tube
15
to prevent the accessory parts coming loose
from the accessory holder
10
unintentionally
during operation.
Put the accessory holder
10
back on the alu-
minium suction tube
15
after vacuuming.
Cleaning, care and maintenance
Emptying the dust collector
To empty the dust collector
20
, it must be removed
from the main unit
4
.
Proceed as follows to empty the dust collector
20
:
Switch the product off using the On/Off
button
18
(see Fig. A).
Remove the dust collector
20
from the main
unit
4
by pushing the release button
22
on
the base of the dust collector
20
(see Fig. G)
and carefully removing the dust collector
20
as
shown in figure H.
Hold the dust collector
20
over a waste bin.
The distance to the dust collector should be
as small as possible so that the dust does not
