Silvercrest SHAZ 22.2 E6 - Initial Use; Selecting, Assembling and Disassembling Accessories

37 GB/IE
- Once all the LEDs are continuously lit, the
rechargeable battery
2
is fully charged.
The rechargeable battery control display
2b
goes
out when the charging process is complete and you
remove the mains adapter
8
from the mains socket
or pull the mains cable connector plug
9
out of the
charging socket
3
of the rechargeable battery
2
.
Once the main unit
4
is switched on using the On/
Off button
18
, the LEDs on the rechargeable
battery control display
2b
light up and show the
charge level of the rechargeable battery
2
.
Note: If the rechargeable battery runs out of power
during operation in MAX mode, the charging process
can only be started after waiting some time (max.
45 minutes). The LEDs will not light up during this time.
This is not a defect of the rechargeable battery, but
rather an integrated safety mechanism.
Initial use
Selecting, assembling and
disassembling accessories
Aluminium suction tube:
The aluminium suction tube
15
serves as an exten-
sion, for example, to access hard-to-reach spots with
the crevice nozzle
12
and as a connection piece
between the electric floor brush
13
and the main
unit
4
.
You can attach all the included accessory parts at
the bottom end of the aluminium suction tube
15
.
Insert the aluminium suction tube
15
from
below into the opening on the main unit
4a
intended for this purpose until it audibly clicks
into place.
Remove the aluminium suction tube
15
from
the main unit
4
by pushing the upper release
button
19
and removing the aluminium suction
tube
15
from the main unit
4
.
15
15 a
14
15
19
4a
20
4
Electric floor brush:
The electric floor brush
13
is suitable both for vacu-
uming smooth floors and carpets. It has a rotating
brush roller
13 a
for taking in hair and fluff.
Attach the aluminium suction tube
15
to the
main unit
4
as previously described.
Insert the electric floor brush
13
into the open-
ing on the aluminium tube
15 a
intended for this
purpose or alternatively directly into the opening
on the main unit
4a
intended for this purpose.
The electric floor brush
13
must audibly click
into place; only then is it properly attached.
Press the release button
14
(aluminium suction
tube
15
) or
19
(main unit
4
) to remove the
electric floor brush and pull the electric floor
brush
13
out of the aluminium suction tube
15
/
the main unit
4
.
