GB
6
Right Hand Female Bolt Slots
• Placetheworktopfacedown
• PlacethejigfacedownwithtwoplasticpegsinthecountersunkMalePegHoles(5)whichare
indicatedbyan'M'
• PlacetheremainingtwopegsintheBoltPegHoles(7)whichareindicatedbya'B'
• Positionthejigovertheworktopasshown,beforesecuringthejiginpositionwithG-clamps
FEMALE
• Theboltslotsneedtobecuttoadepthof20mm.Donotexceed8mmcuttingdepthwith
eachcut
• Followthepattern,makingoneextrapassacrossthecuttocleanoffexcessmaterial
Right Hand Male Cut
• Placetheworktopfaceup
• PlacethejigfacedownwithtwoplasticpegsinthecountersunkMalePegHoles(5)andpushthe
jigrmlyagainstthepostformededge
NOTE:Beforeclamping,ensurethejigispositionedcorrectly,sothattheworktopwillnotbecut
tooshortforthejoint.
• OncethejigisinpositionsecurermlywithG-clamps
• Tostart,placetherouteronthelefthandsideofthejig.Alwayscutfromlefttoright
• Onlycuttoan8mmdepthwitheachpass.Repeattheprocessuntilthecutiscomplete
• Makeoneextrapassacrossthecuttocleanoffexcessmaterial
MALE
Right Hand Male Bolt Slots
• Placetheworktopfacedown
• Withthejigfacingdown,placetwoplasticpegsintheMalePegHoles(5)
• PlacetheremainingtwopegsintheBoltPegHoles(7)
• Positionthejigovertheworktopasshown,beforesecuringthejigintopositionwithG-clamps
MALE
• Theboltslotsneedtobecuttoadepthof20mm.Donotexceed8mmcuttingdepthwith
eachcut
• Followthepattern,makeoneextrapassacrossthecuttocleanoffexcessmaterial
633488_Manual.indd 6 15/06/2017 15:54
