9.1 RSSI and Noise Floor Reporting
The type/length/value for RSSI and noise floor reporting are listed in the following table:
Report Type
Data Type
Information
5009
Empty string ""
Begin of RSSI report
5010
Float
Revision number for RSSI report
5000
Integer
Raw signal power of first antenna, represented
in half dBm steps.
5001
Integer
Raw signal power of second antenna
represented in half dBm steps.
5002
Integer
Raw signal power of third antenna represented
in half dBm steps.
5003
Integer
Raw signal power of fourth antenna
represented in half dBm steps.
5004
Integer
Raw noise power represented in half dBm
steps.
5005
32-bit integer
Sync signal power (from digital domain, see
note below).
5006
32-bit integer
Sync noise power (from digital domain, see
note below).
5007
16-bit integer
Node ID of the radio.
5008
32-bit integer
Report sequence number, increments for every
report, resets after 9999.
1
Empty string ""
End of report.
Table 30 RSSI Reporting Format
Note:
The sync noise and power (types 5005, 5006) are special values obtained after packet processing in the
digital domain. They cannot be directly compared to the raw signal and noise values. To obtain an SNR
from these values the user needs to run the below formula on these values:
X = sync signal power;
Y = sync noise power;
