SIM7600E_SIM7600E-H-PCIE_Hardware_Design_V1.00 11 2017-11-23

TD-HSDPA/HSUPA: 2.2 Mbps(UL), 2.8 Mbps(DL)

LTE CAT 4 ：150 Mbps (DL)

LTE CAT 4 ：50 Mbps (UL)

LTE CAT 1 ：10 Mbps (DL)

LTE CAT 1

：

5 Mbps (UL)

Antenna

GSM/UMTS/LTE main antenna.

UMTS/LTE auxiliary antenna

GNSS antenna

GNSS

GNSS engine (GPS,GLONASS and BD)

Protocol: NMEA

SMS

MT, MO, CB, Text and PDU mode

SMS storage: USIM card or ME(default)

Transmission of SMS alternatively over CS or PS

USIM interface Support identity card: 1.8V/ 3V

USIM application toolkit

Support SAT class 3, GSM 11.14 Release 98

Support USAT

Phonebook management

Support phonebook types: SM, FD, LD, RC, ON, MC

Audio feature

SIM7600E-PCIE do not support audio interface. SIM7600E-PCIEA

product support analog audio interface.

One analog signal output with 32Ω load resistance,50mW output

power, and one analog input.

UART interface

A full modem serial port by default

Baud rate: 300bps to 4Mbps(default:115200bps)

Autobauding baud rate: 9600,19200,38400,57600,115200bps

Can be used as the AT commands or data stream channel.

Support RTS/CTS hardware handshake and software ON/OFF flow

control

Multiplex ability according to GSM 07.10 Multiplexer Protocol.

USB USB 2.0 high speed interface

Firmware upgrade Firmware upgrade over USB interface or FOTA

Physical characteristics

Size: 50.80*31*5.35mm

Weight: less than 12g

Temperature range

Normal operation temperature: -30°C to +80°C

Extended operation temperature: -40°C to +85°C*

Storage temperature -45°C to +90°C

*Note: Module is able to make and receive voice calls, data calls, SMS and make GPRS/WCDMA/HSPA+/LTE

traffic in -40℃~+85℃. The performance will reduce slightly from the 3GPP specifications if the temperature

is outside of the normal operating temperature and still within the extreme operating temperature.
