SIM7600E_SIM7600E-H-PCIE_Hardware_Design_V1.00 33 2017-11-23
6. Electrical Specifications
6.1 Absolute Maximum Ratings
The absolute maximum ratings are described by the following table. Module may be damaged beyond these
ratings.
Table 23: Absolute maximum ratings
Symbol Parameter Min Type Max Unit
V
CC
VCC input voltage -0.3 - 3.6 V
V
IO
Voltage at digital pins
(1.8V digital I/O) *
-0.3 - 2.1 V
*Note: These parameters are for digital interface pins, such as I2C,UART,GPIO.
6.2 Recommended Operating Conditions
Please refer to the follow table for recommended operating conditions.
Table 24: Operating Conditions
Symbol Parameter Min Type Max Unit
V
CC
3.3V Input voltage 3.0 3.3 3.6 V
V
IO
Voltage at digital pins (1.8V
digital I/O)
0 1.8 1.95 V
T
OPER
Operating temperature -40 +25 +85
℃
T
STG
Storage temperature -45 +25 +90
℃
6.3 Operating Mode
6.3.1 Operating Mode
The table below summarizes the various operating modes of SIM7600E-PCIE.
Table 25: Operating Mode
Mode
Function
Normal
operation
GSM/UMTS/LTE
Sleep
In this case, the current consumption of module will be
reduced to the minimal level and the module can still receive
paging message and SMS.
GSM /UMTS/ LT E
Idle
Software is active. Module is registered to the network, and
the module is ready to communicate.
SIMCOM CONFIDENTIAL FILE

SIM Tech SIMCom SIM7600E-PCIE Specifications

General

Category	Control Unit
Manufacturer	SIMCom
Model	SIM7600E-PCIE
Form Factor	PCIe
GSM Bands	850/900/1800/1900 MHz
Operating Voltage	3.3V
Module Type	LTE module
Network Standard	LTE, UMTS, GSM
LTE Category	Cat 4
Frequency Bands	LTE/UMTS/GSM
LTE Bands	B1/B3/B7/B8/B20/B28
UMTS Bands	B1/B5/B8
Data Rate LTE	DL 150Mbps, UL 50Mbps
Data Rate UMTS	up to 42 Mbps
GNSS	GPS/GLONASS
Interface	PCIe, UART, USB
Power Supply	3.3V
Weight	10g
Certifications	CE, RoHS
Operating Temperature	-40°C to +85°C

Summary

Module Package Details

PCI Express Mini Card Connector Pin Description

Detailed description of each pin on the PCI Express Mini Card connector.

Hardware Interface Guide

Power Supply

Specifies the recommended voltage and current requirements for the module.

PERST#

Details the PERST# pin function and recommended reference circuit for reset.

W_DISABLE#

USB 2.0

USIM Interface

UART Interface

Radio Frequency Specifications

GSM/WCDMA/LTE RF Specifications

Provides conducted transmission power and operating frequencies for various bands.

RF Antenna Connector

GNSS

Electrical Characteristics and Operation

Absolute Maximum Ratings

Lists the maximum allowable voltage and current ratings for the module.

Recommended Operating Conditions

Specifies the voltage, temperature, and humidity for normal operation.

Operating Mode

Power saving mode

Current Consumption

Lists typical current consumption values for various operating states and bands.

Electro-Static Discharge

Provides ESD characteristics and handling precautions for the module.

Module Packaging and Shipping

Technical Appendices

Important Safety Precautions

Safety caution

Outlines safety precautions for using the cellular terminal or mobile device.
