SIM7600E_SIM7600E-H-PCIE_Hardware_Design_V1.00 36 2017-11-23
LT E-FDD B8
@5Mbps 22.6dBm Typical: 560mA
@10Mbps 22.6dBm Typical: 600mA
LT E-FDD B20
@5Mbps 23.4dBm Typical: 689mA
@10Mbps 23.6dBm Typical: 698mA
LT E-TDD B38
@5Mbps 23.0dBm Typical: 512mA
@10Mbps 23.0dBm Typical: 544mA
LT E-TDD B40
@5Mbps 23.0dBm Typical: 495mA
@10Mbps 23.0dBm Typical: 512mA
LT E-TDD B41
@5Mbps 23.0dBm Typical: 428mA
@10Mbps 23.0dBm Typical: 450mA
Note: In the table above the current consumption value is the typical one of the module tested in the
laboratory. In the mass production stage, there may be some difference.
6.5 Electro-Static Discharge
SIM7600E-PCIE is an ESD sensitive component, so more attention should be paid to the procedure of handling
and packaging. The ESD test results are shown in the following table.
Table 27: ESD characteristics (Temperature: 25℃, Humidity: 45 %)
Part
Contact discharge
Air discharge
VBAT,GND
+/-6K
+/-12K
Antenna port
+/-5K +/-10K
USB
+/-4K +/-8K
UART
+/-3K +/-6K
Other PADs
+/-3K +/-6K
