Smart Machine Smart Decision

SIM7600E_SIM7600E-H-PCIE_Hardware_Design_V1.00 9 2017-11-23

2.1 Hardware Interface Overview

SIM7600E-PCIE provides various hardware interfaces via Mini PCI Express card connector.

● Power Supply

● PERST#

● W_DISABLE#

● LED_WWAN#

● WA KE #

● USB Interface

● USIM Interface

● UART Interface

● I2C Interface

● Analog Audio Interface* (Only provided on PCIEA products)

SIMCOM CONFIDENTIAL FILE
