SIM Tech SIMCom SIM7600E-PCIE User Manual

Smart Machine Smart Decision
SIM7600E_SIM7600E-H-PCIE_Hardware_Design_V1.00 35 2017-11-23
6.4 Current Consumption
The current consumption is listed in the table below.
Table 26: Current Consumption (VCC=3.3V)
GNSS
GNSS supply current
(AT+CFUN=0,with USB connection)
@ -140dBm，Tracking Typical:35mA
GSM sleep/idle mode
GSM/GPRS supply current
(GNSS off，without USB connection)
Sleep mode@ BS_PA_MFRMS=2 Typical: 2.8mA
Idle mode@ BS_PA_MFRMS=2 Typical: 18mA
UMTS sleep/idle mode
WCDMA supply current
(GNSS off，without USB connection)
Sleep mode @DRX=9 Typical: 3.3mA
Idle mode @DRX=9 Typical: 17.5mA
LTE sleep/idle mode
LTE supply current
(GNSS off
，
without USB connection)
Sleep mode Typical: 4.6mA
Idle mode Typical: 17.5mA
GSM Talk
EGSM900
@power 33.0 dBm Typical: 293mA
DCS1800
@power 29.5dBm Typical: 227mA
UMTS Talk
WCDMA B1
@Power 22.5dBm Typical: 511mA
WCDMA B5
@Power 23.6dBm Typical: 595mA
WCDMA B8
@Power 23.0dBm Typical: 603mA
GPRS
EGSM900( 1 Rx,4 Tx )
@power 28.7 dBm Typical: 647mA
DCS1800( 1 Rx,4 Tx )
@power 25.3 dBm Typical: 526mA
EGSM900( 3Rx, 2 Tx )
@power 31.9 dBm Typical: 433mA
DCS1800( 3Rx, 2 Tx )
@power 28.4 dBm Typical: 350mA
EDGE
EGSM900( 1 Rx,4 Tx )
@power 23.3dBm Typical: 430mA
DCS1800( 1 Rx,4 Tx )
@power 21.9 dBm Typical: 439mA
EGSM900( 3Rx, 2 Tx )
@power 25.9 dBm Typical: 246mA
DCS1800( 3Rx, 2 Tx )
@power 25.2 dBm Typical: 265mA
HSDPA data
WCDMA B1
@Power 24dBm Typical: 478mA
WCDMA B8
@Power 24dBm Typical: 430mA
LTE data
LT E-FDD B1
@5Mbps 22.5dBm Typical: 597mA
@10Mbps 22.5dBm Typical: 608mA
@20Mbps 22.5dBm Typical: 687mA
LT E-FDD B3
@5Mbps 22.9dBm Typical: 656mA
@10Mbps 22.6dBm Typical: 684mA
@20Mbps 22.8dBm Typical: 746mA
LT E-FDD B5
@5Mbps 22.5dBm Typical: 564mA
@10Mbps 22.5dBm Typical: 598mA
LT E-FDD B7
@5Mbps 23.4dBm Typical: 762mA
@10Mbps 23.4dBm Typical: 707mA
@20Mbps 23.4dBm Typical: 726mA
SIMCOM CONFIDENTIAL FILE
