SIM7600E_SIM7600E-H-PCIE_Hardware_Design_V1.00 27 2017-11-23
Table 17: E-UTRA operating bands
E-UTRA
Operating
Band
Uplink (UL) operating band
Downlin
k (DL) operating
band
Duplex
Mode
1
1920 ~1980 MHz
2110 ~2170 MHz
FDD
3 1710 ~1785 MHz 1805 ~1880 MHz FDD
5 824～849 MHz 869～894MHz FDD
7 2500~2570MHz 2620~2690MHz FDD
8 880 ~915 MHz 925 ~960 MHz FDD
20
832~862MHz
791~ 821
FDD
38
2570 ~2620 MHz
2570 ~2620 MHz
TDD
40
2300 ~2400 MHz
2300 ~2400 MHz
TDD
41 2496 ~2690 MHz 2496 ~2690 MHz TDD
Note: Operating frequencies of LTE TDD B41 for the SIM7600E-PCIE is 100MHz BW, 2555～2655
MHz
Table 18: Conducted receive sensitivity
Frequency Receive sensitivity(Typical)
Receive sensitivity(MAX)
EGSM900 < -109dBm
3GPP
DCS1800 < -109dBm
3GPP
WCDMA 2100 < -110dBm
3GPP
WCDMA 900 < -110dBm
3GPP
WCDMA 800 < -110dBm
3GPP
LTE FDD/TDD
See table 26.
3GPP
Table 19: Reference sensitivity (QPSK)
E-UTR
A band
1.4 MHz
Standard
3 MHz
Standard
5 MHz
Standard
10 MHz
Standard
5 MHz Test
Resort
15 MHz
Standard
20 MHz
Standard
Duplex
Mode
1 - - -100 -97 -101 -95.2 -94 FDD
3 -101.7 -98.7 -97 -94 -99 -92.2 -91 FDD
5 -103.2 -100.2 -98 -95 -99 FDD
7 -98 -95 -97 -93.2 -92 FDD
8
-102.2
-99.2
-97
-94
-102
FDD
20 -97 -94 -97 -91.2 -90 FDD
38 - - -100 -97 -101 -95.2 -94 TDD
40 - - -100 -97 -101 -95.2 -94 TDD
41 - - -99 -96 -101 -94.2 -93 TDD
