4 Technical Data
Hopper
FX 2004 FX 2504
Material 1.4301 1.4301
Diameter
∅200 x 330 mm ∅250 x 407 mm
Feeding volume 2,5l 5 l
Material outlet DN 100 DN 100
Feeding pipe DN 38 oder DN 50 DN 38 oder DN 50
Weight 9,2 kg 11,4 kg
Filter
FX 2004
FX 2004
optional
FX 2504
FX 2504
optional
Filter size 0,06m² 0,06 m² 0,08 m² 0,08 m²
Material Polyamid PE- needle felt Polyamid PE- needle felt
Size
∅210 x 90
conical
∅210 x 90
conical
∅240 x 140
conical
∅240 x 140
conical
Weight 0,160 kg 0,160 kg 0,190 kg 0,190 kg
Valve filter backwash Blower unit EKO
FX 2004 FX 2004/ 2504
Designation 2/2 WGV Designation EKO
Connection 1/2“ Power 1,0kW
Control voltage 24 V Operating voltage 240V
Weight 2,05kg
Pneumatic
Mixing valve - option Clean out valve - option
Designation 4/2 WGV 4/2 WGV
Connection 1/8“ 1/8“
Control voltage 24 V 24 V
Weight 0,273 kg 0,273 kg
5/2 way solenoid valve
5/2 way solenoid valve
2/2 WSV
