24
IQ POWER CONTROL STATION
WITH SENSOR TECHNOLOGY
5201263 Rev D
– This will lead to a page where general and specific files and documentation
for the Anybus module are available.
– For example: From the Anybus CompactCom 30 series web page,
clicking on “EtherNet/IP” and “File/Document Downloads” then
selecting “Anybus IP config – Utility for module TCP/IP configuration”
leads to a utility for setting the IP address of the Anybus EtherNet/IP
module.
– Within the Anybus CompactCom web pages are; software design
guides, driver packages, help documents, configuration utilities,
network interface specific information (appendix documents) and other
technical support information.
– The information available on the Anybus web site provides support
for customer developed software to operate the customer’s PLC,
data polling device, or computer network connected to the Anybus
CompactCom module.
Control Station Fieldbus Interface List
Anybus Module
Network Interface
Anybus Model Code
Simco-Ion Kit P/N
EtherNet/IP AB6214 (AB6224) 5051872
PROFIBUS DP-V1 AB6200 5051873
DeviceNet AB6201 5051874
PROFINET IO AB6215 5051876
Modbus TCP AB6213 5051877
Modbus RTU AB6203 5051880
ControlNet AB6220 5051885
These modules are typically installed at the time of manufacture. Modules and
related circuitry may be retrofitted at a later date provided the IQ Power Control
Station is returned to the factory or authorized service center for unit modification
and module installation.
Connect the Anybus CompactCom module to the PLC, data polling device or
computer network using an appropriate network cable.
Address / Device Number
The address / device number is a number 1 thru 10 on the IQ Power system. All IQ
Power and IQ Easy devices are assigned an address of “1” at the factory. The address
serves to differentiate devices and is also used to define association between devices.
NOTE – If multiple IQ Power/IQ Easy devices are connected to the Control
Station, each static neutralizer must be given a unique address/ device
number.
