35
IQ POWER CONTROL STATION
WITH SENSOR TECHNOLOGY
5201263 Rev D
8. PARTS AND ACCESSORIES
Part Description Part Number
Control Station (100-240 VAC input) 4015868
Remote Mount Control Station (100-240 VAC input) 4016669
Line Cord, North American/Japan 120/100 VAC 4106272
Line Cord, North American 230 VAC 4106274
Connector Kit, Relay Output / STBY 5051855
Mounting Kit, Under Panel (2 brackets to mount Control Station beneath a
panel)
5051898
Mounting Kit, Remote Under Panel (hardware to separate display from Control
Station and mount display (only) beneath a panel)
5051901
Modular Cable (RJ-45 to RJ-45, IQ Power 8-conductor, crossover wired) for use
between Control Station and IQ Power BPS / HL / RDM “COMM 1”
DO NOT USE Standard Ethernet Cables (see Figure 1)
0.91 meter [3 foot] black
2.13 meter [7 foot] black
4.27 meter [14 foot] black
7.62 meter [25 foot] black
15.24 meter [50 foot] black
30.48 meter [100 foot] black
4520785
4520786
4520787
4520784
4520844
4520845
Cable (RJ-45 to straight M12 connector)
IQ Power BPS to IQ Easy Sensor Bar with straight connector at Sensor Bar end
4.57meter [15 foot] Straight M12 Connector
9.14 meter [30 foot] Straight M12 Connector
5051840
5051844
Cable (RJ-45 to right angle M12 connector)
IQ Power BPS to IQ Easy Sensor Bar with right angle connector at Sensor Bar end
4.57 meter [15 foot] Right Angle M12 Connector
9.14 meter [30 foot] Right Angle M12 Connector
5051841
5051845
Cable (IQ Easy M12 connectors at both ends) for use between Control Station
and IQ Easy, IQ Power MPS or Fantom with straight connector at device end
1.5 meter [4.9 foot] Straight / Straight M12 Connector
5 meter [16.4 foot] Straight / Straight M12 Connector
10 meter [32.8 foot] Straight / Straight M12 Connector
20 meter [65.6 foot] Straight / Straight M12 Connector
30 meter [98.4 foot] Straight / Straight M12 Connector
5051939
5051791
5051792
5051793
5051794
