IQ POWER CONTROL STATION
WITH SENSOR TECHNOLOGY
5201263 Rev D
5. OPERATION
NOTE – Before switching on the Control Station; ensure all BPS, HL and
HLC-RDM units in the system are properly grounded.
A. BPS, MPS, HL, HLC static neutralizer power supplies connected to a Control
Station will energize regardless of power switch setting.
B. Switch the Control Station power switch (located near the power inlet) to on
(“I”).
C. The Control Station will start by displaying the Home Page. In the
upper portion of the display is an icon for System Settings (a gear).
Tapping on the gear icon opens the System Settings page and allows
adjustment of system operating parameters and operating parameters that can
be applied to all devices in the system. For example:
• Device Name for the system
• Add’l Info
• Data Log - On/Off
• Data Log Time Base (selectable interval)
• Up Time - total run time for system
• Panel Mode (where more than one display panel is on the system)
• Legacy Mode for use with earlier devices
• Password (to change)
• Software Version
• System Information Utility/Fieldbus Module Utility
To adjust settings, tap the pencil icon to the right of the setting. The settings are
password protected. From the factory, the default password is “PASSWORD”.
Changing the password: Tap on the pencil icon for Password in the System Settings
page. Enter the current password to proceed. A prompt will appear to set a new
password. The maximum password length is 14 characters
Resetting the password: If the password is forgotten, enter “2257” when
prompted for the password. This will reset the password to the factory default of
“PASSWORD”.
System Information Utility: There are two diagnostic screens available, the System
Information Utility and the Fieldbus Module Utility (where a fieldbus is installed).
Both screens provide a “snapshot” that can be used for diagnostic purposes. The
System Information Utility provides a comprehensive list of devices connected
to the system, their firmware version number and accumulated run time. The
Fieldbus Module Utility displays, where a fieldbus is installed, the contents of the
fieldbus data buffer and other system information typically found in the fieldbus
output. Both utilities are provided in the event troubleshooting is needed. If
factory assistance required, a simple photograph (.jpg) of the diagnostic screen(s)
will expedite troubleshooting.
