IQ POWER CONTROL STATION
WITH SENSOR TECHNOLOGY
5201263 Rev D
Display Configuration
CAUTION – Electrical Shock Hazard
Disconnect input power before opening unit. Do not connect input power
with unit open.
ATTENTION – Risque De Choc Électrique
Mettre hors tension avant l’ouverture de l’unité. Ne rebranchez pas avec
l’unité ouverte.
The Control Station may be reconfigured, placing the connector panel at the “top”
of the unit, if desired (factory configuration is with the connector panel at the
“bottom” of the unit). To reconfigure the unit, remove line cord from power inlet
connector. Remove screws from sides of unit. Lift cover off of unit. The interface
display rests on brackets built into the case. Carefully lift the interface display just
off unit and rotate 180˚, use care not to stress the electrical cables. Place interface
display back onto brackets built into case. Check that no cables are pinched by
looking through gaps at top and bottom of unit. Move cables if necessary. Replace
cover and secure with screws on sides.
System Configuration
The Control Station and related IQ Power / IQ Easy devices can be configured in
a variety of ways. The range of static neutralizing and sensing equipment available
allow for flexibility in meeting application requirements. When a static neutralizing
device is paired with a static sensing device, the pair is considered a single device.
The following figures each illustrate a fundamental configuration with specific
equipment. Fundamental configurations may be combined on a system to meet the
particular needs of the application.
