IQ POWER CONTROL STATION
WITH SENSOR TECHNOLOGY
5201263 Rev D
3. SPECIFICATIONS
Input Power 100-240V~ 50/60 Hz, 4A max (IEC 320 inlet)
Output Voltage 24 VDC (all IQ Power and IQ Easy connectors)
Device Port USB-A
Network Port Ethernet
Interface 10.2” Color TFT LCD (backlit) with resistive touch screen
Operating Temp 39°C [102°F] max
Mounting Slots M6 or M5 [1/4” or #10] hardware (not included)
Enclosure Steel, blue epoxy powder coated
Dimensions 197L x 314W x 118H mm [7.75”L x 12.38”W x 4.65”H]
Weight 5.2 kg [11.4 lb]
