Fonderie Sime S.p.A. - Via Garbo, 27 - 37045 Legnago (Verona) - Tel. +39-0442-631111 - Fax +39-0442-631292 - www.sime.it
ETONLEDOMNOITPIRCSEDEDOCNOITISOP
EPYT .DOC EGAPETAD
• Recommended stock parts - Componenti da tenere a scorta
ETONLEDOMNOITPIRCSEDEDOCNOITISOP
78 6201505 Arbre pour trimmer Ø 6
Trimmer spindle Ø 6
79 • 6226602 Ressort de fixation tuyaux
Pipe fixing spring
80 2211610 Bornier à 6 fast-on
Earth faston
81 6226429 Joint OR Dalmar 121
O-ring 121
82 6289901 Protéction tableau de bord
Control panel protecting cover
83 6290301 Couvercle cables panneau de bord
Control panel cable cover
84 6290201 Couvercle raccord. therm. d’ambiance
Room stat connection cover
85 6290102 Poignée blanche Ø 40
White knob Ø 40
86 6009585 Plaque de support tableau de bord
Control panel bracket
87 6290019 Guichet
Flap door
88 • 6131401 Micro pour fluxostat
Microswitch for flowmeter
89 5191900 Micro vanne de déviation + support
Divertor valve microswitch + support
90 6226605 Ressort de fixation
Fixing spring
91 2051100 Ressort de fixation capillaires
Retaining spring
92 6288310 Porte antérieur chambre étanche
Sealed chamber front panel
93 6001210 Regard de flamme
Peephole
94 6287331 Jaquette
Casing
95 2013302 Plaquette pour vis à tôle
Fastener for self tapping screw
96 2004510 Vis 8Px7/8”
Screw 8Px7/8”
97 6112420 Vis tableau de bord
Control panel screw
98 6028623 Diaphragme air Ø 86
Air diaphragm Ø 86
99 5192200 Kit joint chambre étanche
Gasket for sealed chamber
100 6177544 Robinet gaz 3/4”
Gas cock 3/4”
101 • 6295501 Filtre chauffage 3/4”M x 3/4”M
C.H. filter 3/4”M x 3/4”M
102 6264746 Tuyau connexion filtre-echangeur
Pipe conn. C.H. filter-C.H. exchanger
103 6281512 Régulateur du débit
Water rate adjuster
104 • 6269810 Cable pour allumage
Ignition cable
105 6229101 Support pressostat
Smoke pressure switch bracket
106 6238602 Bouchon pour sortie pilostat SIT
SIT pilot plug 0.972.041
107 • 6162401 Joint pour vanne gaz
Square gasket
108 6120511 Nipple 3/4” x 3/4” OT
Nipple 3/4”x3/4” OT
109 6290351 Couvercle bornier
Terminal strip protection cover
110 6177542 Robinet gaz 3/4”
Gas cock 3/4”
111 6177543 Robinet installation
C.H. illet fitting
112 6142450 Courbe 1/2” x 15
Bend 1/2” Ø 15 connect. boiler to jig
113 6142451 Courbe 3/4” x 18
Bend 3/4” Ø 18 connect. boiler
114 6142452 Courbe 1/2” x 15
Bend 1/2” Ø 15 connect. boiler
115 6142453 Courbe 3/4” x 18
Bend 3/4” Ø 18 connect. boiler
3820127/495 FORMAT.ZIP 35 BF CDN 23.02.2009 4/5
