* Includes: Seal plate, O-Ring, and seal plate insert.
** Includes: Water slinger, seal plate O-Ring or gasket, shaft seal, diffuser pad,
and diffuser O-Ring or gasket.
§ Includes: Pump body, nozzle, venturi, and venturi O-Ring.
§§
Includes: Seal and Gasket Kit (Key No. 3), impeller, seal plate insert,
and diffuser.
Key Part 3105P 3107P
No. Description 1/2HP 3/4HP
1 Motor A100CLL A100DLL
2 Seal Plate Assembly* N203-12P N203-12P
3 Seal and Gasket Kit** FPP1530 FPP1530
4 Pump Body Assembly§ N176-35P N176-35P
5 Overhaul Kit§§ FPP1520 FPP1521
6 Pressure Switch TC2151 TC2151
Repair Parts 11
For parts or assistance, call Simer Customer Service at 1-800-468-7867 / 1-800-546-7867
