SD200 DRUM MODULE OPERATION
REAR PANEL
1
Trigger Input Jacks
The included multipin cable connects
the pads and the pedals to the module.
BACK PANEL
1
AC Adapter Input
Connection for the included 9V DC power
adapter.
2
USB Port
Used for connecting the SD200 module to a
computer.
3
AUX Input
 
devices to module.
4
Output
¼” stereo audio outputs to connect to external
audio sources.
2 3 41
