10
Setting Up and Calibrating the Expression Pedal.
The Tune Maestro is equipped with Expression Pedal to provide expressive musical phrases as the musician is
playing. To setup the expression pedal, all that is needed is calibration. Therefore, the menu has been setup to
provide the calibration aspect of the pedal.
To calibrate the expression pedal, click the G# key as shown below; this will start
flashing the F and G keys. Keep in mind the expression pedal requires two values
to be calibrated, Max and Min.
Max Calibration:
Press the G key as shown below, the display will indicate “UP”, at this point
press on the calibration pedal forward to reach Maximum position as the picture
below shows, then press the G key again.
Min Calibration:
Press the F key as shown below, the display will indicate “DN”, at this point
press on the calibration pedal backwards to reach Minimum position, then
press the F key again.
