6
Setting Up The Main Quarter Tune.
While the 4 keys are flashing, C#, D#, F#, and G#, press the C# as shown below:
The display will show the default value, which should be -50.
Using the dial, set the desired tune, keep in mind that clockwise will set the tune in the positive direction, and
counterclockwise will set the tune in the negative direction.
Note: the dial color will change to the direction of tuning, i.e. if the tune chosen is positive, the dial LED color will be
“Green”, and if the tune chosen is negative, the dial LED color will be “Red”.
Once the necessary tune is chosen, either click the “Dial” or click the “C#” key to confirm the selection. Once the
main quarter tune is asserted, the 4 LEDs, C#, D#, F#, and G# will start flashing again indicating the user is at the main
menu.
Setting Up MIDI Channel.
To setup the MIDI channel for each instrument press the “D#” button as shown below. Once the D# is pressed,
then C, D, and E buttons will start flashing, indicating the user is at the “Submenu”. Each button corresponds to one
of the MIDI ports.
C MIDI Port 1
D MIDI Port 2
E MIDI Port 3
