Simoniz 039-8563-8 - Page 27

Ref.
Description
Qty.
1
Handle Foam
1
2
Handle
1
3
ST4×25
4
4
Locknut M5
12
5
Back Panel
1
6
Hose Hook
1
7
High Pressure Hose
1
8
Plug
2
9
Square Neck Bolt
2
10
Securing Nut Assembly
2
11
Frame
1
12
Drain Pipe
1
13
Air shield
1
14
Gasoline Engine
1
15
Washer 8
3
16
Circlipφ8
1
17
M8X40
1
18
Circlipφ16
2
19
Plain Washerφ16
2
20
9”Wheel
2
21
Wheel Shaft
2
22
Spring Wire
2
23
Circlip
2
24
Spring Lock
2
25
Injection Hose
1
26
GQX-41F High Pressure Pump
1
27
Thermal Relief
1
28
LocknutM8
4
Ref.
Description
Qty.
29
Rubber Foot
2
30
M8×45
2
31
Rubber Foot Washer
2
32
Inlet Hose
1
33
Inlet Hose Nut
1
34
Detergent Tank
1
35
M5×40
6
36
Lower Gun Holder
1
37
M5×50
1
38
Detergent Tank Cap
1
39
M8×60
2
40
Rope Guider
1
41
Washer 5
1
42
Padding Block
4
43
Upper Gun Holder
1
44
Gun Holder Connector
1
45
M5×65
4
1-46
0° Nozzle (red)
1
2-46
15° Nozzle (yellow)
1
3-46
25° Nozzle (green)
1
4-46
40° Nozzle (white)
1
5-46
Detergent Nozzle (black)
1
47
Nozzle Grommet
5
48
2#B Gun
1
49
2#B Wand
1
