Lift the main frame (A) with one hand and at-
tach one of the wheels (B) by pressing the
wheel’s pin and inserting the wheel shaft into
the main frame (A). Align the pin with the hole
on the frame (A) until it snaps in. Repeat this
procedure for the second wheel (B) on the op-
posite side.
Letters refer to Scope of Delivery diagrams on pages 8 and 9.
Insert upper gun holder (G) to the groove of
handle assembly(C) until the end as per in-
struction.
Position handle assembly (C) and main frame
(A) as per instruction and connect them by
square neck bolt (I), then secure by nut (J).
Repeat this procedure for the second on the
opposite side.BE SURE to secure the nut to
make the handle upright.
