Simplex 4010 User Guide

6 S4010-0003-5 6/2013
MFG. Model Number Coil Details MFG. Model Number
A
N
S
U
L
*AUTOMAN II-C Assembly; solenoid 17728;
coil 25924
12 VDC, 458 mA
ASCO
8210A107 (097617-005D coil) 1/2” NPS, 5/8” orifice,
24 VDC
AUTOMAN II-C Explosion-Proof Releasing
Device; solenoid 31492; coil 31438
24 VDC, 467 mA
8210G207 (238310 coil) 1/2” NPS, 1/2” orifice
*AUTOMAN II-C Assembly; solenoid 68739;
coil 25924,
12 VDC, 458 mA 8211A107 (097617-005D coil) 24VDC
Solenoid Electric Actuator; solenoid 73111;
coil 73097
24 VDC, 1 A HV2628571 (23810 coil) N.C. 1/2” NPS, 1/2” orifice
*CV90 HF Electric Actuator 73327; may use
73606 in-line resistor for 12 VDC
9 VDC max,
450 mA
HV2648581 (23810 coil) N.O. 1/2” NPS, 1/2” orifice
R8210A107 (097617-005D coil) 1/2” NPS, 5/8” orifice
LP CO2 w/ASCO solenoid 422934, 24 VDC, 442 mA T8210A107 (097617-005D coil) 1/2” NPS, 5/8” orifice
LP CO2 double action solenoid 430948 24 VDC, 438 mA
Pyro-
Chem
ECH Electrical Control Head (551201)
LP CO2 3-way selector valve solenoid
433419
24 VDC, 438 mA Explosion-Proof Electric Actuator (570147)
Electric Actuator 24 VDC solenoid 570537 24 VDC, 250 mA Removable Electric Actuator (570209) 0.2 A
LPG
Solenoid 26114002 for Solenoid Coupling
Assemblies: 21006401 & 21006402; &
LPG128/145/190/230-50/55 FM-200 valves;
and LPG128-90UL iFLOW & FM-200 valves
24 VDC, 542 mA
S
k
i
n
n
e
r
71395SN2ENJ1NOH111C2 (Skinner coil H111C2) 1/4”, NPS, 1/16”
73212BN4TN00NOC111C2 (Skinner coil C111C2) 1/2”, 5-300 psi
73212BN4TNLVNOC322C2 (Skinner coil C322C2) 1/2”, NPS, 0.92 A, 250 psi
73218BN4UNLVNOH111C2 (Skinner coil H111C2)
73218BN4UNLVNOC111C2 (Skinner coil C111C2) 1/2”, NPS, 5/8 in. orifice
* 12 VDC coils, either wire two in series for 24 VDC activation, or, if available from manufacturer, use series resistor
Suppression Release Peripheral 4090-9005 and 4090-9006
Communications IDNet, one address
RAC Output Rating, with 4010 control panel* 1 A maximum @ nominal 24 VDC, regulated
NAC Power Requirements
NOTE: 4010 NACs are
rated 2 A; 4009 IDNet
NAC Extender standard
NACs are rated at 2 A,
Extender expansion NACs
are rated 1.5 A
Voltage 16 to 32 VDC (nominal 24 VDC)
Supervisory Current
No additional current required, circuit appears as standard end-of-line (EOL)
NAC loading
Alarm Current
Reference
(RAC current =
actuator current)
RAC Current NAC Current
0.5 A 0.845 A
0.75 A 1.28 A
0.87 A 1.5 A
1 A 1.71 A
Wire Connections
Screw terminals for input and output wiring, 18 to 12 AWG wire
(0.82 mm
2
to 3.31 mm
2
)
IDNet Wiring Distance Reference
Up to 2500 ft (762 m) from the IDNet communications source module
Up to 10,000 ft (3048 m) total Class B wiring distance including T-Taps
Compatible with Simplex 2081-9044 Overvoltage Protectors
Dimensions See installation reference on page 8
Operating Temperature 32° to 120° F (0° to 49° C) indoor operation only
Operating Humidity Range 10 to 90% RH at 90° F (32° C)
Coil Supervision Module 2081-9046
Construction Epoxy encapsulated
Dimensions 1-3/8” W x 2-7/16” L x 1-1/16” H (34 mm x 62 mm x 27 mm)
Wiring 18 AWG (0.82 mm
2
) wire leads, color coded
Current Rating 2 A maximum; internally fused at 3 A, non-replaceable
* Refer to data sheet S4100-0040 for application information when using the Suppression Release Peripheral with the 4100U Series Fire
Alarm Control Panels.
Specifications
Compatible UL Listed Valves and Actuators
