Simplicity 1692024 - Page 111

6 - 41
6 General Repair
6C Foot Controls Repair
1 SPRING, Extension
2 SPACER, 25/64 x 1 x 1-7/32
3 BUSHING, Plastic
4 SPACER, 3/8 x 43/64 x 29/64
5 SPRING, Drive
6 GUARD, Spring “L”
7 BRAKE PEDAL ASSY.
8 PAD, Brake Pedal Assy.
9 CLIP RING, 5/8
10 CAM, Parking Brake
11 SPACER
12 PULLEY, Idler, Backside
13 PULLEY, V, Idler
14 SPRING
15 BELT STOP
16 ROD, Clutch
17 ARM ASSY., Brake
18 IDLER ARM ASSY.
19 SWITCH, Actuator
20 ARM, Brake Pedal Assy.
21 SPRING, Tension
22 ROD, Parking Brake
23 KNOB
24 ROD, Brake
25 BRACKET, Idler
26 PULLEY
27 NUT, Hex, 3/8-16
28 LOCKWASHER, 3/8
29 LOCKWASHER, 5/16
30 NUT, Hex, Full, 5/16-18
31 COTTER PIN
32 WASHER, Plain, 5/16
33 WASHER, Plain, 3/4
34 NUT, Hex Nyloc, 5/16-18
35 NUT, Hex, Esna, 3/8-16
36 CAPSCREW, Hex Hd., 3/8-16 x 1
37 WASHER, Plain, 1/4
38 WASHER, 13/32 x 1-1/4 x 1/16
39 WASHER, Plain, 3/8
40 CAPSCREW, Hex Hd., 3/8-16 x 3-1/4
41 COTTER PIN, 1/16 x 3/4
42 WASHER, Plain, 3/8
43 NUT, Hex, Flange, Whiz, 3/8-16
44 CARRIAGE BOLT, 3/8-16 x 1-3/4
45 WASHER, 5/8 I.D. x 1-1/4 O.D. x 5/64 Thk.
46 WASHER, 21/64 I.D. x 1-1/4 O.D. x 5/64 Thk.
47 CARRIAGE BOLT, 5/16-18 x 1-1/4
REF.
NO. DESCRIPTION
Hydro-Gear 216 Models
