Simplicity 1692024 User Manual

7 - 59
7 Transmission Repair
7E Tuff Torq K210A
1. Arm, Shift
2. Pin, Roll
3. Pin, Roll
4. Packing
5. Washer
6. Ring, Internal Snap
7. Fork, Shift
8. Pin, Roll
9. Ball, 3/16"
10. Ball, 3/8"
11. Spring
12. Shaft, Fork
13. Shifter
14. Conical Spring Assembly
15. Washer Assembly
16. Shift Key
17. Roller
18. Spring, Ringed
19. Arm, Range
20. Arm, Interlock
21. Nut
22. Case, B, Differential
23. Washer
24. Gear Set, Differential
25. Washer, Differential Pinion
26. Shaft, Differential Pinion
27. Case, A, Differential Assembly
28. Gear, 64 Tooth, Final
29. Bolt
30. Bolt
31. Ring, Snap
32. Pulley, Input
33. Ring, Snap, External
34. Washer
35. Seal
36. Ring, Internal Snap
37. Sleeve
38. Bearing
39. Collar
40. Input Gear, 9 Tooth, Spiral
41. Drum, Brake
42. Shoe Set, Brake
43. Ring, Snap, External
44. Cover, Brake
45. Shaft, Cam Lever
46. Brake Assembly, (Includes Part Nos. 41-45)
47. Bolt, (includes washer)
48. Roll Pin
49. Fitting
50. Plug, Seal
51. Seal TC
52. Bearing, Needle
53. Ring, Internal Snap
54. Seal TC
55. Housing, Transmission, R.H.
56. Shaft, Axle, R.H.
57. Bearing
58. Washer
59. Ring, Internal Snap
60. Cap, Oil
61. Packing
62. Screw
63. Washer
64. Ring, Internal Snap
65. Bearing
66. Housing, Transmission, L.H.
67. Packing
68. Plug
69. Screw, Self Threading
70. Plate
71. Cap, Sealing
72. Bearing
73. Gear, 35 Tooth, Ring
74. Collar
75. Chain, Roller
76. Sprocket, 9 Tooth
77. Shaft, Reduction
78. Gear, 62 Tooth, Shift
79. Collar, Neutral
80. Washer
81. Sprocket, 16 Tooth
82. Shaft, Shift
83. Bearing
84. Washer
85. Shim Set
86. Gear, 32 Tooth, Reduction
87. Gear, 26 Tooth, Reduction
88. Gear, 23 Tooth, Reduction
89. Gear, 18 Tooth, Reduction
90. Gear, 14 Tooth, Reduction
91. Gear, 49 Tooth, Shift
92. Gear, 38 Tooth, Shift
93. Gear, 34 Tooth, Shift
94. Gear, 30 Tooth, Shift
95. Gear, 24 Tooth, Shift
96. Toothed Washer
97. Bearing
98. Shaft, Axle, L.H.
