8 Mower Deck Repair
Deck & Arbors - Early Models
1 6 BEARING
2 3 HOUSING, Arbor, Top
3 3 ADAPTER, Blade
4 3 WASHER, Spring
5 3 WASHER, Spline
6 3 SHIELD, Grass, Upper
7 18 SCREW, Hex, Taptite, 5/16 x 3/4
8 3 COLLAR, Mower Arbor
9 3 SHAFT, Arbor (Incl. Ref. No. 8)
10 3 SHAFT & BEARING ASSY. (Center & Outer)
(Incl. Ref. Nos. 1, 9, & 27)
11 1 HOUSING ASSY., 44" (Orange)
1 HOUSING ASSY., 44" (Black)
12 1 HOUSING ASSY., 50" (Orange)
1 HOUSING ASSY., 50" (Black)
13 3 SHIELD, Grass, Bottom
14 3 WASHER, Shim
15 3 HOUSING ASSY., Arbor, Bottom
(Incl. Ref. Nos. 15 & 20)
16 1 COVER, Arbor
17 3 BLADE, Mower, 44"
18 1 PULLEY ASSY.
19 2 PULLEY ASSY., Deck Drive
20 3 GREASE FITTING
21 1 COVER, Arbor
22 1 CLAMP
23 1 SPRING
24 1 PLUG, Hole
25 1 DEFLECTOR, Plastic
26 1 ROD, Deflector, Front
27 3 GASKET, Foam
28 3 BLADE, Mower, 50"
29 2 NUT, Hex, 1/4-20
30 2 LOCKWASHER, 1/4
31 3 LOCKWASHER, 7/16
32 1 WASHER, Plain, 5/16
33 2 CAPSCREW, Hex Hd., 7/16-14 x 1-1/4
34 3 CAPSCREW, Hex Hd., 7/16-14 x 1
35 7 SCREW, Hex, Taptite, 5/16 x 1/2
36 2 CARRIAGE BOLT, 1/4-20 x 7/8
37 3 WASHER, Plain
38 2 WASHER, Flat
39 1 NUT, Push On
40 1 CAPSCREW, Hex Hd., 7/16-14 x 3-1/4
Ref. Qt. Description Ref. Qt. Description
Deck & Arbors - Early Models
