8 - 5
8 Mower Deck Repair
Deck & Arbors - Later Models
1 3 NUT, Hex, Flange, 9/16-8
2 6 WASHER, Belleville
3 1 PULLEY
4 1 HUB, Double Pulley
5 3 PULLEY
6 1 HUB, Double Pulley
7 3 COVER, Arbor Housing
8 3 BEARING
9 3 SPACER
10 3 SPACER
11 3 BEARING
12 3 GASKET, Foam
13 3 ARBOR HOUSING ASSY. (Incl. Ref. No. 14)
14 3 FITTING, Grease
15 1 COVER, Arbor
16 25 SCREW, Hex, Taptite, 5/16-18 x 3/4
17 3 WASHER
18 1 SHAFT, Arbor (LH)
19 3 SHIELD, Grass, Lower
20 3 BLADE, Mower, 16-1/8”
21 3 WASHER, Hex
22 3 WASHER, Spring
23 3 CAPSCREW, Hex, Hd., 7/16-14 x 1
24 2 SHAFT, Arbor (Center & RH)
25 1 MOWER HOUSING ASSY., Mower (Orange)
25 1 MOWER HOUSING ASSY., Mower (Black)
26 1 COVER, Arbor
27 2 CARRIAGE BOLT, 1/4-20 x 7/8
28 2 NUT, Push On
29 2 WASHER, Plain
30 1 CLAMP
31 1 WASHER, Plain, 5/16
32 1 SPRING
33 2 LOCKWASHER, 1/4
34 2 NUT, Hex, 1/4-20
35 1 ROD, Deflector, Front
36 1 PLUG, Hole
37 1 DEFLECTOR, Plastic
38 1 HUB, Pulley
Ref. Qt. Description Ref. Qt. Description
Deck & Arbors - Later Models
