5 Electrical Troubleshooting
Electric Lift Motor
5 - 8
NOTE: Use standard hardware torque
specifications chart unless otherwise noted.
7
4
3
8
9
12
11
2
1
5
10
6
Figure 3. Electric Lift Motor
