Simplicity 560 - Table of Contents

Contents.
IDENTIFICATION & ACCESSORIES .... . 1
SAFETY RULES . 2
DECALS .. .1........ .4
OPERATION .'.... 6
• CONTROLS...s.y.. .4........... . 6
v .CHECKS BEFORE EACH STARTUP .......... 7
.DEFLECTOR ADJUSTMENT. 7
SCRAPER BAR HEIGHT ADJUSTMENT. 7
> freewheeling a
STARTING THE ENGINE . . ... ...'... ’B .
GROUND SPEED SELECTION ..... . 8
* ENGINE SPEED T.v... 9
■ *$' STARTING & STOPPINGOPERATION .^....v*9 v : ■
| C AFTER EACH USE . 10
NORMAL CARE ....... 11
. OFF SEASON STORAGE 1-1
STARTING AFTER STORAGE . . . . . . ..11
■ d J
NORMAL CARE CHART .. 11
CHECK AUGER GEAR CASE
LUBRICATION ..11
LUBRICATE THE SNOWTHROWER .. 12
CHECK TIRE PRESSURE. 12
INSPECT THE BATTERY .. 13
SERVICE . 1 4
TROUBLESHOOTING .. . V. , . ....14
BELT REPLACEMENT.. 1 6
TRACTION DRIVE TENSION . 18
AUGER DRIVE TENSION . . .. „ . 18
A SPEED SELECTOR ADJUST. ......;. .... 18
, • SHEAR PIN REPLACEMENT ......... f... ., 19
DISCHARGE CONTROL ADJUST. ............ 19
SPECIFICATIONS ...,........• 20
COMMON REPLACEMENT PARTS . ... 22
PARTS MANUAL AVAILABLE J?. . ...... 23
Manufacturer’s Numbers
Model 560 - 1690543, 1690775, 1691374
Model 760 - 1690544, 1690903
Model 860- 1691023, 1691024, 1691376, 1691401, 1691403
Model 870 - 1690545, 1690678, 1690776, 1690778; 1691377 ,
Model 1070- 1691378 ’ ? 'C;
Model 1080- 1690546, 1690679, 1690777, 1690779, 1691540
