i Normal Care i
TRACTOR LUBRICATION
Lubricate the tractor as shown in figure 7
thru 10. Refer to Table 2, Lubrication Chart,
for correct lubricant and procedure.
Lube Points: Two Pivot Points of Gear
Shift Lever.
Figure 7. Location: Under Seat
jTable 2. Lubrica tion Cha rt
12
Lube Points: Two Pivot Points of
PTO Lever.
Figure 8. Location: Under Left
Footrest.
