5. DC MICROAMPERES:
Range: 0-50µA
Voltage Drop: 250mV
6. DC MILLIAMPERES:
Ranges: 0-1-10-100-500 mA
Voltage Drop (Approx.): 250 mV, 255 mV, 300 mV, 500 mV
7. DC AMPERES:
Range: 0-10A
Voltage Drop (Approx.): 255 mV
NOTE: The 10A range is not internally fused.
8.
9. * ACCURACY:
DC Voltage Ranges: 2% of Full Scale
DC Current:
0-50 µA Range: 1.5% of Full Scale
Other Ranges: 2% of Full Scale
**AC Voltage Ranges: 3% of Full Scale
Frequency Response: Referenced to 100 Hz (Figures 4-4 and 4-9)
Resistance Ranges:
R X 1: 2.5° of Arc
R X 100: 2° of Arc
R X 10,000: 2° of Arc
10. DECIBELS:
Range: –20 to +10 dB, –8 to +22 dB, 0 to +30 dB,
+6 to +36 dB, +20 to +50 dB
Reference Level: With zero dB power level equal to 1 mW across a
600⍀ line.
11. BATTERIES:
Voltage: 1.5V, 9V
NEDA No.: 13F, 1604
12. FUSE: F1 1A, 250V, type 3AG, quick acting Littlefuse Type
312001, F2 2A, 600V Littlefuse Type BLS or 2A
600V, Bussman Type BBS.
13. TEST LEADS: 1 red, 1 black, 48" long.
14. SIZE: 5-1/2” x 7" x 3-1/8 ” (13.34 x 17.78 x 7.94 cm)
* Accuracies specified are for the 260 in a horizontal position.
** Responds to the average value of an AC current, and is calibrated to indicate
the RMS value of a pure sine wave
ECNATSISER1XR001XR000,01XR
egnaR000,2-0 ⍀ 000,002-0 ⍀ M02-0 ⍀
gnidaeRretneC21 ⍀ 0021 ⍀ 000,021 ⍀
tiucriCnepOlanimoN
egatloV
V5.1V5.1V9
tiucriCtrohSlanimoN
tnerruC
Am521Am52.1Aµ57
