10
15. WEIGHT: 3 lbs. (1.359 kg)
16. ***RATED-CIRCUIT-TO-
GROUND VOLTAGE: 1000V AC/DC Max.
***Per ANSI C 39.5 April 1974: “The specified voltage with respect to ground,
which may be safely and continuously applied to the circuit of an Instrument.”
1.9 Definition of Accuracy
The voltage and current accuracy of this Instrument is commonly expressed as a
percent of full scale. This should not be confused with accuracy of reading (indi-
cation). For example, +2% of full scale on the 10 volt range allows an error of
±0.20V at any point on the dial. This means that at full scale, the accuracy reading
would be ±2%, but at half scale it would be ±4%. Therefore, it is advantageous to
select a range which gives an indication as near as possible to full scale.
1.10 Safety Considerations
This Operator’s Manual contains cautions and warnings alerting the user to haz-
ardous operating and service conditions. This information is flagged by CAU-
TION or WARNING symbols throughout the publication, where applicable, and is
defined on the inside front cover of the manual under NOTES AND SAFETY
INFORMATION. Adhere to these instructions in order to ensure the safety of
operating and servicing personnel and to retain the operating conditions of the
Instrument.
TABLE 1-2. Items and Accessories Furnished with this Instrument
Quantity Description Catalog No.
1 Test Lead Set – one red and one black
((48” long) each with combination probe tip
and removable rubber-sleeved alligator clip. 00043
*1 1.5 Volt, D Cell, NEDA 13F
*1 9.0 Volt Cell, NEDA 1604
2 1 Amp, 250V Fuse, Littlefuse Type #312001
1 2A, 600V Fuse, Littlefuse Type BLS or
(Bussman Type BBS)
1 Operator’s Manual 6-114338
* Batteries are standard items, replaceable from retail stores.
TABLE 1-3. Additional Accessories
Description Catalog Number
Deluxe Case......................................................................................... 00812
Leatherette Ever-Redy Hard Case, Drop Front ................................... 00805
Model 150-2 Amp-Clamp ..................................................................... 00545
Model 151-2 Line Splitter ..................................................................... 00544
