2
|
6 AUTO key
Press to activate last active mode (AUTO or NoDrift), and to display the mode pop-
up menu.
Repeat pressing the key to toggle the pop-up menu options.
7 NAV key
Press to activate Nav (Navigation) mode.
8 WORK/Thruster key
Press to display work profile options. Repeat short presses to toggle the work
profile options.
Press and hold to activate or de-activate the thruster.
9
and
11
< and > (port and starboard) keys
In Standby and FU mode: Press to activate Non-Follow Up (NFU) steering.
In automatic modes: Press to change the set heading/set course to port or to
starboard.
10 Turn key
Press to display the Turn-dialog.
The autopilot page
A
B
E
D
C
The autopilot page includes:
• A: Heading repeater
• B: Status panel
• C: Mode info panel
• D: Rudder bar
• E: Quick menu - displayed by pressing the MENU, WORK/Thruster or the TURN key
Icon Description
Active thrusters
Active alarm
Active warning
Picture freeze indicator
