Simrad AP24 User Manual

Technical specifications | 49
Data converted from SimNet/NMEA2000 to NMEA0183
(TX) and vice versa (RX).
NMEA0183 sentence TX (max rate [Hz]) RX
APB 0.5 x
BWC 0.5 x
BWR x
DBT x
DPT 0.5 1
1)
x
GGA x
GLL 0.5
2)
x
HDG 4 x
HDM x
2)
HDT 4 x
HSC 0.1
MTW 0.2 x
MWV Relative Wind 1 x
MWV True Wind 1 x
RMA x
RMB 0.5 x
RMC 0.5 x
RSA 3.33
VHW 0.5 x
VTG 0.5 x
VLW 0.2 0.5
1)
x
VWR x
WPL x
XTE x
ZDA 0.5 x
ZTG x
Open cells indicates no transmission or reception.
1)
Applies only for units with P/N – S/N code AA
2)
Applies for units with P/N – S/N code BA onwards

Simrad AP24 Specifications

General

Display Type	LCD
Power Supply	12/24 V DC
Water Resistance	IPX6
Operating Temperature	-15°C to +55°C
Interface	NMEA 2000
Compass	Not included
Control Modes	Auto, Nav, Wind
