System wiring example
12/24 V
DC
12 V DC
A
UT
O
PI
LO
T
CO
M
PU
TE
R
COMPASS
SPEED / DEPTH
SENSOR
DRIVE UNIT
RUDDER
FEEDBACK
AP48
AUTOPILOT
CONTROLLER
AUTOPILOT
CONTROLLER
Micro-C T-connector Micro-C
terminator, 120 Ohm Micro-C
power cable NMEA 2000
backbone Micro-C drop cable
MASTHEAD
UNIT
GPS
SENSOR
T
T
T
MULTIFUNCTION
DISPLAY
