| 41
The alarm system | AP70/AP80 Operator Manual
The Alarm dialog
All new alarms and warnings activates the alarm dialog. The dialog will be closed when the
message is acknowledged.
If more than one message is activate, this will be indicated in the alarm dialog. Only the cause
for the most recent message will be displayed. The remaining messages are available in the
Alarms listing as described on page 41.
Single active alarm Multiple active alarms
Acknowledging a message
There is no time-out on the alarm message or siren. These remain active until you
acknowledge it or until the reason for the alarm is removed.
The following options are available in the alarm dialog for acknowledging a message:
Option Result
ACK Sets the alarm state to acknowledged, meaning that you are aware of the alarm
condition. The siren will stop and the alarm dialog will be removed.
The alarm icon will however remain active, and the alarm will be included in
the alarm listing until the reason for the alarm has been removed
Mute Mutes the siren locally. The alarm dialog remains on the display
The alarm dialogs
The system includes three different alarm displays:
• Active alarms
- List of all active messages
• Alarm history
- Alarm events, including alarm type and time/date
• Alarm settings
- List of all alarms that can be enabled and configured by the user
