Specications | NAIS-500 User Manual
Specications
Parameter Value
Dimensions 152 x 98 x 52 mm (L x W x H)
Weight 260 g
Power DC (9.6 V - 31.2 V)
Average power consumption 180 mA at 12
VDC
Peak current rating 2 A at 12 VDC
GPS receiver
(AIS internal)
50 channel IEC 61108-1 compliant
Electrical
interfaces
USB
NMEA 0183, default 38,400 baud (bi-
directional)
NMEA 0183, default 4,800 baud (bi-
directional)
NMEA 2000 LEN=1
Connections VHF antenna connector (SO-239)
External GPS antenna connector (SMA)
USB type mini-B
NMEA 2000 standard connector
12 way power input/NMEA 0183/external
switch
VHF transceiver AIS transmitter x 1
AIS receiver x 2 (one receiver time shared
between AIS and DSC)
Frequency: 156.025 to 162.025 MHz in 25 kHz
steps
Output power 33 dBm ± 1.5 dB
Channel
bandwidth
25 kHz
Channel step 25 kHz
Modulation
modes
25 kHz GMSK (AIS, Tx and Rx)
25 kHz AFSK (DSC, Rx only)
