ABOUT
This document describes the basic operation of the NSX multi-function display (MFD) unit.
For the latest version of this document and other app guides, we recommend you download the
Simrad mobile app or visit: www.simrad-yachting.com.
TURN UNIT ON/OFF
To turn the unit on, press and hold the power button. A beep sounds to indicate it is powering up.
To turn the unit o, press and hold the power button, or select Power o from the Quick access
menu.
A B
External power control
Power to the unit can be controlled by an external switch or other units. For details about
available power options, refer to the unit’s installation manual.
¼ Note: If your MFD is controlled by an external power source, it cannot be powered o using the
power button. Pressing and holding the power button puts the unit in standby mode. To wake
the unit, press the power button again.
A Power button
B Touchscreen
7
