84 |
Dimensional drawings | RS40/RS40-B User Guide
Handset Cradle Charger (BC-12)
171.6mm
[6.75"]
65.7mm
[2.59"]
55.7mm
[2.19"]
58.0mm
[2.28"]
54.6mm
[2.15"]
74.9mm
[2.95"]
32.9mm
[1.29"]
