18 |
Installation |
RS90 Installation Manual
Installing a handset cable connector
Each wired handset cable includes a connector assembly that must
be installed in a bulkhead, dashboard or other suitable panel.
Mounting
sur
face
Bezel
Connector cov
er
Socket body
Drill 24 mm diameter hole
to clear socket body
17
19
