4.6 Dimensions
Instruction Manual
27
E04074
4.5 Technical Specification
Power Supply 12v DC (10.8v - 15.5v DC)
Channel Capability 55 international channels 1-28, 60-88 simplex & semi-duplex
UK : includes M (previously 37) and M2
USA : includes 0, 29, 89, 75, 76, Wx1-10 receive only.
Scandinavia : leisure or fishing channels as appropriate.
Canada : Canadian and USA channels.
Private Channels Up to 16 private channels*
External Speaker Impedance 8Ω
Transmit -
Frequency Range 155-163Mhz
Power Output 1 watt or 25 watts
Current Consumption 5.5A (25 watts)
1.3A (1 watt)
Harmonic and Spurious Emissions < 0.25µW
Hum / Noise < -40dB
Modulation ±5kHz
Receive
Audio Output Power 2 watts
Current Consumption 340mA (Full Volume, illumination on)
190mA (Fully Squelched, illumination off)
Sensitivity < 0.5µV emf for 20 dB SINAD
Harmonic and Spurious Emissions < -2nW
Hum / Noise < -40dB
Adjacent Channel Selectivity 70dB
Intermodulation Rejection 70dB
* Contact local Simrad Technical Dealer for further details of channel programming etc.
Environmental
VHF Radio Waterproof to IP66
Fistmike / Telephone Handset Waterproof to IP67
Compass Safe Distance 1m (3.3ft)
RT62 & RT64
26
E04074
185mm (7.4in)
158mm (6.2in)
66mm (2.6in)
22mm (0.9in)
47mm (1.8in)
55mm (2.2in)
79mm (3.1in)
213mm (8.4in)
54mm (2.2in) 70mm (2.8in)
