2.2 Operation - Scanning Versions
The radio is switched on using the volume knob. The VHF
starts up automatically on channel 16* at maximum power
(25w).
*This can be changed - contact Simrad Agent for details
2.2.1 Function (F) / Backlight ( )
NOTE - Secondary functions are only available on scanning versions of
the VHF.
Several of the keys have secondary functions in addition to the
main function. These are accessed by pressing F, then the
appropriate key within two seconds (do not hold the F key
down). When F is pressed, the F legend will appear on the
LCD for the two seconds it is active. Pressing another key
within this time will access its second function.
Backlighting
The LCD backlighting is switched on and off as a secondary
function of the F key. To turn the backlighting on/off press F
twice (Fig 2.2). If the F key is held down the second press, the
lighting will step through five brightness levels. Release the
key when the desired lighting level is reached.
Instruction Manual
7
E04074
2 OPERATION
2.1 Location of Controls
The RT62 and RT64 VHFs are very simple to operate, using
only five buttons and three rotary knobs to access a variety of
functions. The functions available will depend on whether the
radio is a scanning or non-scanning version (scanning func-
tions are not permitted in certain countries).
Control Legend Primary function Secondary function
1 F/ Used to access secondary functions* Switch backlighting on/off
2 1/25 Select transmit power (1w / 25w) Enter selected channel into memory*
3 D/W Dual Watch Inhibit channel from scan*
4 SCN/P Scan all channels* / Select working channel† Scan channels in memory sequentially*
5 16 Select channel 16
6 Sq Squelch adjust
7 Vol On–off / Volume adjust
8 Ch Channel select knob
* Scanning versions only † Non-scanning versions only
RT62 & RT64
6
E04074
Fig 2.1 - Control functions
1267
3
45
8
1267
3
45
8
Scanning
version
Non-scanning
version
PRESSED TWICE
Fig 2.2 - Switching backlighting on
