26 |
Drawings |10kW and 25kW Installation Manual
25 kW scanner
2254 mm (88.74”)
458 mm (18.03”)
260 mm
(10.24”)
300 mm (11.81”)
142 mm (5.59”)
536 mm (21.10”)
463 mm
(18.23”)
290 mm (11.42”)
 Note: mounting templates are provided.
