Contents | 10kW and 25kW Installation Manual
Contents
2 Introduction
4 Pre installation checks
4 Check the parts
4 Choose the scanner location
5 Power boat installations
6 How to nd the A-B Line:
6 How to nd the theoretical maximum detection range
7 Reduce false echoes and shadow zones
9 Hardware mounting
9 Install the radar processor
10 Install the scanner
12 Wiring
12 Guidelines
12 Radar scanner: 10 kW
15 Radar scanner: 25 kW
18 Radar processor connections
21 Pinouts
21 Scanner cable
22 NMEA / COMMS cable
23 Speci cations
23 TXL-10S-4/TXL-10S-6TXL-25S-7
25 Drawings
25 10 kW scanner
26 25 kW scanner
27 Radar processor
