－8－
OPERATING METHODS
1). Select a place that near door and window, install the exhaust duct (the installation
method please refer to P19), put the exhaust duct out of the door, do not close the door
and window tightly, leave enough space for air flow, for example, open the window or
door to keep a good ventilation.
2). Press "MODE" key to select "COOL" mode.
3). Press "TEMP" key to set the suitable temp.16℃-30℃.
4). Press "FAN" key to select the suitable fan speed, (HIGH, MD, LOW).
When the unit is running in COOL mode, in order to keep a good cooling effect,
please pay more attention to:
１）． If there is the direct sunlight at the window, please use the curtain to shield .
２）． Do not use other heat sources in the air conditioning room.
Please close the door and window to obtain a better dehumidifying effect:
Press "MODE" key, select "DRY" mode, the unit will run in the "DRY" mode, at the
same time, the upper motor is running at the low speed, it is not adjustable.
When the air conditioner is used as dehumidifier, it is no need to install the exhaust duct.
1). Press "MODE" key, to select "FAN" mode.
2). Press "FAN SPEED" key to choose from the HIGH, MD, LOW fan speed options.
Press "MODE" key to select "AUTO" mode, the microcomputer process will
automatically choose COOL, DRY, HEAT mode, for ensuring the indoor constant
temperature efficiency.
Press "MODE" key to choose "HEAT" mode, at the same time, compressor and lower
motor stop running, only PTC is running, the upper motor is running at the set fan speed.
COOL mode
CAUTION
DRY mode
CAUTION
FAN mode
AUTO mode
HEAT mode
When in cooling or dehumidifying mode, the dew water will be drained into the tank.
When the tank gets full, the indicator will flash, and the buzzer will sound eight times,
LCD window shows error code “H8”，at the same time the unit stops running.
WATER
Cut off power supply, move the appliance to a suitable place to pull out the plug and
pour out the water in tank. When water is drained out completely, re-insert the plug
back into the drainage pipe to avoid dew water leakage. (As figurre shown below Fig 1)
When
restarting the appliance,it must be set again.
METHOD OF
DRAINAGE
If the appliance is placed in a position admitting to drain water, you also can connect the
drain hose to the drain port to drain water.
DRAINAGE
Drainage Pipe
Rubber Plug
Fig 1
Fig 2
Fig 3
(As figurre shown below Fig 2--Fig 3)
(61
O
F~86
Ｏ
F).
