2
SUMMARY
1
This MOBILE AIR CONDITIONER is a small, moveable air conditioner. It possessed the
functions of COOL, HEAT, DRY and the Separate Ventilation, and depends on different places, it
can be moved as will. It is fit for home and office use, especially fit for the house with many rooms.
With the compact configuration, excellent workmanship, elegant appearance, it looks like a standing
Benz car. It is convenient for moving, energy saving, and with low noise.
Note: Please read this manual carefully before operating the unit, the manual is used for reference,
and the technical parameters are subject to change without notice.
WORKING PRINCIPLE
With the help of upper motor, the airflow of indoor pass through the evaporator becomes the
cooled wind, but with the help of lower motor, the airflow of indoor pass through the condenser
becomes the heated wind. There is two duct systems designed in its structure. The heated wind is discharged
by the rear outlet, the cooled wind is discharged by the front outlet, flow-guided by the louver, and it
brings the gentle cooling airflow, and the low temperature environment is maintained.
The Working Principle
Cooled wind
Upper
motor
Lower
motor
Evaporator
Airflow 1
Airflow 2
Capillary
Heated wind
Condenser
